Every trail, every steep climb, every thrilling descent. Nothing is out of bounds with the Reign E . This proven trail ripper gives you the power to enjoy the best parts of the ride again and again.
Features
Trail Technology: Proven Maestro rear suspension (160mm) and a powerful but compact SyncDrive Pro motor boost your capabilities on steep climbs and rugged descents. Progressive geometry with a shorter rear end and longer reach allows for superior handling and agility on technical terrain.
Total Control: RideControl Ergo 3 offers integrated, user-friendly button controls that are easy to use. The Giant E-bike App provides tuning options and E-bike specific fitness tracking.
Long-lasting Power: Climb steep mountains and enjoy ripping descents all day long with the new downtube-integrated EnergyPak battery system featuring 800Wh of capacity.
Specifications
Motor: SyncDrive Pro 2, 85Nm, powered by Yamaha
Controller: RideControl Ergo 3, grip integrated
Display: RideControl GO, frame integrated LED display, ANT wireless display compatible
Battery: EnergyPak Smart 800Wh, EnergyPak Plus range extender compatible
Charger: EnergyPak 6A smart charger
Connectivity: Giant RideControl App enabled, ANT wireless display signal with E-bike profile
Sizes: S, M, L, XL
Colours: Raw Aluminium
Frame: ALUXX SL-grade Aluminium, Advanced Forged Composite Upper Rocker, 160mm Maestro suspension system, flip chip, UDH hanger, 12x148mm thru-axle
Fork: SR Suntour Durolux 38 Boost EQ, 170mm travel, 44mm offset, RC2, 15LH-110
Shock: Fox Float DPS Performance, EVOL Large Volume sleeve, custom tuned
Handlebar: Giant Contact Trail, 35mm
Grips: Giant Tactal Pro-E, single lock-on
Stem: Giant Contact SL 35mm S: 40mm, M: 40mm, L: 40mm, XL: 50mm
Seatpost: Giant Contact Switch travel-adjustable dropper, remote S: 110-140mm travel / 30.9 x 395mm, M: 140-170mm travel / 30.9 x 470mm, L: 170-200mm travel / 30.9 x 530mm, XL: 170-200mm travel / 30.9 x 530mm
Saddle: Giant Romero Trail
Pedals: Platform
Shifters: Shimano CUES, SL-6000, 1x11
Front Derailleur: MRP 1X HD2 custom co-molded chain guide
Rear Derailleur: Shimano CUES, U6000, Shadow
Brakes: Shimano BR-MT420, 4-piston, hydraulic disc, 203mm
Brake Levers: Shimano Deore, I-spec EV
Cassette: Shimano Cues LinkGlide, CS-LG400-11, 11-50T, 11-speed
Chain: Shimano Cues CN-LG500
Crankset: Praxis Wave™ 36T Cold Forged 4130 premium steel, Praxis e-Cadet custom forged crankarm set S: 160mm, M: 160mm, L: 165mm, XL: 165mm
Bottom Bracket: N/A
Rims: Giant AM 29" [F] 27.5" [R], tubeless ready
Hubs: Shimano MT410, Boost, Center-Lock, [F] 110x15, [R] 148x12mm HG Drive Body thru-axle
Spokes: Sapim E-Lite [R] Race [F], e-bike optimised
Tires: Maxxis Minion DHF 29x2.6" foldable, tubeless, EXO , 3C MaxxTerra [F] Maxxis High Roller II 27.5x2.5" foldable, tubeless, DoubleDown, 3C MaxxTerra Compound [R]
Extras: Tubeless kit (liquid, valves, levers, manual, tool)
Lock: Torx 25 Battery Lock with built-in torque limiter
Mfr Claimed Weight
TBC
